Portable laser marker Colibrì 20 W

New portable laser marking system COLIBRI': generates a laser beam from the source to the lightweight portable head via a flexible fiber cable. It is the only portable laser that fully meets all operator safety requirements (Class 1)

• The only portable marking laser in Class 1 safety!
• Perfect for marking large parts and components
• Up to 32 auxiliary axes and infinite combinations for integration with robots or PLCs
• Easy to use with the innovative Automator marking software

COLIBRI' is an extremely comfortable modular system: the main block houses the source and the board with the electronic parts in two separate areas, so that dust, which might enter from the cooling fans, does not affect the electronic board, which is therefore isolated. The galvanometers are housed, together with the lenses, in the portable head block.

A convenient and functional 8-inch LCD touchscreen monitor allows the marker to be operated through the marking software, without the need for a PC.

Fiber lasers allow a significant increase in source power, without compromising the size of the laser dot. This ensures a deep and accurate marking result at higher powers and high system efficiency.

Laser type NB:Yb 1064 nm

Power: 20W

Safety class: 1

FYBRA^II  is operated by Automator software that is versatile in application and easy to use, even by operators without specific technical training or CAD knowledge.

• Multilingual menus
• Handles “DataMatrix” barcodes, 2D codes, QR codes, PDF codes
• Easy import of DXF vector drawings
• Easy import of raster graphics, BMP, JPEG, .JPG, GIF
• Complete set of laser parameters such as laser speed or power
• Text, Arc text, text on curved lines
• Line, rectangle, polygon, circle and arc
  TTF Font® (windows property)
• Graphic preview display Texts with date, serial numbers, shift codes and year/month/day
• Markings with fill or outline only
  Template (object to be marked as background)
• Proportion scaling, movement, rotation, group creation of each object on screen

Watch our video

Discover how quick and easy it is to mark with the portable laser Colibrì in safety class 1!
